55W H Type UVC Light Tubes Ultraviolet 254nm 533mm UV Disinfection Tube

Product Categories

Ningbo Uv Light & Electricity Co., Ltd.

Contact Now

55W H Type UVC Light Tubes Ultraviolet 254nm 533mm UV Disinfection Tube

Name: 55W H Type UVC Light Tubes Ultraviolet 254nm 533mm UV Disinfection Tube
Brand: UV,Yoway
Price: 1 USD

Quality 55W H Type UVC Light Tubes Ultraviolet 254nm 533mm UV Disinfection Tube for sale

Brand Name : UV,Yoway

Model Number : ZW55D17Y(W)-H533

Certification : CE,ROHS

Place of Origin : Zhejiang, China

MOQ : 10 pcs

Price : $1-$20/pcs

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10000 pcs per month

Delivery Time : 5 days

Packaging Details : paper box packing or as required

name : H shape

wattage : 55W

Lamp : single-ended

Lamp Voltage : 122

Lamp current : 326

ITEM : ZW55D17Y(W)-H533

DIAMETER : 17

LENGTH : 533mm

TYPE : OZONE/FREE

BALLAST : YW-HCS-102A

Average lifetime : ＞8000

Contact Now

H shape UV germicidal lamp

55W H Type UVC Light Ultraviolet Disinfection Lamps H Shape 185nm 254nm UV Germicidal Lamp

Product Description

H type UV germicidal lamp is equipped with hot cathode starter,with the sepcification from 5W to 55W ,and a diameter of 12mm and 17mm.

55W H Type UVC Light Tubes Ultraviolet 254nm 533mm UV Disinfection Tube

PRODUCT DETAILS


Made of high quality quartz.2.Average lamp life is 8,000 hours.
lamp cap are G23 and 2G11 are for choice.
Ozone-free lamps(254nm) and ozone-generating lamps (185nm) are for choice.
The 254nm (UV output) was tested in the laboratory.It maybe different when the environment was changed.

ZW40D17Y(W)-H533

No.	Item	Code	Rated value	Unit	Tolerance
1	Lamp Power	P_L	39.8	W	±15%
2	Lamp Voltage	U_L	122	V
3	*Lamp current	I_L	326*	mA
4	Strengh of 254nm @30mm distance		≥152	μw/cm²
5	Steady time of lighting	T_稳	10	min
6	Average lifetime	H	＞8000	h

Product Description

H Shaped UVC Lamp Specification Details

Main body material: High quality Quartz glass
 Base material: Ceramic, aluminum, plastic
 Wattage: can make according to customized request.
Wavelength: 254nm (Ozone free), Or 254nm + 185nm (With Ozone )
 Appearance Type: H shaped.
Lamp base type: G23, GX23, 2G7, 2G11, G32q
 Average Lifetime: ≥8000hrs

1	KITCHEN FUME PURIFICATION
2	DEODORIZATION AND PURIFICATION TREATMENT
3	REMOVE ODOR AND PURIFIY INDUSTRIAL WASTE GAS

Noted: for example: ZW15S(D)25W(Y)-Z436 ,"ZW" means Ultraviolet lamp,"15" means 15w,"S" means double ended pipe line,"D" means single ended pipe line,"25" menas pipe diameter is 25mm,"W" means with the ozone,"Y" means without ozone," Z" means Straight pipe,"436" means pipe length is 436mm)
	ITEM NO.		PRODUCT PICTURE	Dia(mm)	MOQ	PORT	Price($/pcs)	Ballast Price($/set)
	ITEM NO.		PRODUCT PICTURE	Dia(mm)	MOQ	PORT	Price($/pcs)	Ballast Price($/set)
Single ended H Pipe	5W	ZW5D12Y(W)-H85		∅12	100	NINGBO
	7W	ZW7D12Y(W)-H115		∅12	100	NINGBO
	9W	ZW9D12Y(W)-H145		∅12	100	NINGBO
	11W	ZW11D12Y(W)-H215		∅12	100	NINGBO
	13W	ZW13D12Y(W)-H164		∅12	100	NINGBO
	18W	ZW18D17Y(W)-H217		∅17	100	NINGBO
	24W	ZW24D17Y(W)-H317		∅17	100	NINGBO
	36W	ZW36D17Y(W)-H411(386)	60w	∅17	100	NINGBO
	55W	ZW55D17Y(W)-H533	95w	∅17	100	NINGBO

1 Ballast for testing: YW-HCS-102A

2 Instrument for testing: UI2000

3 Testing condition: Temperature:25±1℃ Humidity:30%~50%

4 UV-ray luminometer is tested by UVB-254 probe type of Beijing Normal University,The test values of different illuminance meters are different, and the data are from Youwei Light & Electricity.

Light Source	Quartz Tube
wavelength(nm)	253.7
Instrument for testing:	UI2000
Diameter	17mm
Base face length	533
Head material	aluminium
Single head or double head	Sigle-ended

The ozone free lamp emits 254nm UV light to kill microorganisms directly, ultraviolet photons harm the DNA molecules of living organisms in different ways. In one common damage event, adjacent thymine bases bond with each other, instead of across the “ladder”. This “thymine dimer” makes a bulge, and the distorted DNA molecules will not function properly.

While the ozone generating lamp gives out 185nm UV light to react with oxygen gas in the air or water to form ozone. Ozone is able to destroy cells of microorganism, and it also serves as a kind of strong oxidant to kill biological tissues of microorganism. And based on UV photolysis, our ozone generating UV bactericidal lamps could completely decompose oil, remove fume and other peculiar odor.

The Eight Core Technologies

1.Core filament electronic power processing technology.

2.Use the best quality raw materials----Glass tube UV transmittance>93%. 3.Unique inner coating film and outer coating film technology.

4.Solid mercury----Homemade special mercury fixation to improve light efficiency.

5.Unique patented rapid leak detection technology

6.Unique wick anti-vibration patented technology .

7.The most advanced automated processing equiment in China.

8.Cost advantage and perfect pre-sales and after-sales service.

Application Areas

It could be applied in the electric appliance

such as dynamic air sterilizer,sterilization cabinet as well as the equipments such as the sterilizer,disinfectant devices,deodorizing apparatus and purifier. Operation rooms, sickness rooms. Medical disinfection and air clean machines.

UVC germicidal lamp are widely used in:

---hospital,medical centers,old homes,orphanages

---kindergartens,schools,high schools,universities

---restanrants and hotels ---food industry(meat,milk etc.)

FAQ

Q1: Are you factory or trading company?
 A: We are trading company with factory.

 Q2: Can I have a sample first before bulk order?
 A: Yes. We offer you free sample to test the quality, you only undertake the freight.

 Q3: What's your delivery date?
 A: 3-5 working days for samples and 10-20 days for bulk order.
